Application: HHB801 force control instrument can reduce the amount of ingredients packaging, filling quantitative 4 kinds of material ingredients and other control occasions,
Features: product digital communication interface, with RS232 RS485 band isolation.Analog signal output 0~5V 0~10V 4~20MA (optional)
Standard analog output signals convert force signals into digital signals for communication
Technical specifications:
LED digital tube 6 double row display real-time measurement value value target value ingredient number I/0 status information,
Power off memory function, continue to complete the batching process after power off restart
Control speed fast or slow can be set to set the batch number of reducing batching, automatic stop when the scheduled batch
Static resolution 900,000
Optical coupler three - way relay output, greatly improve the product transmission speed.Switching output
A/D conversion speed: 400 times/second
It can be connected in parallel with 350 ohm 8 sensors
Double window display, peak automatic memory
With automatic zero tracking function
With analog and digital dual filtering function
The measurement range can collect positive and negative signals and display positive and negative values
Embedded design greatly facilitates the installation of electrical cabinets for customers.
It has functions of automatic zero clearing and manual zero clearing
Installation dimension drawing (unit MM):
Hua heng measurement main business: force sensor, weighing sensor, tension pressure sensor, force measurement control instrument, weight amplifier, force meter
To undertake non - standard force weighing sensor custom force sensor of all kinds
Special notice: the product information is for reference only, subject to change without notice, please refer to the actual information.
